SmartNode Multiport FXO VoIP GW- 12 FXO

SmartNode 12 FXO VoIP Gateway 1 Fast Ethernet Internal UI Power
Supports simultaneous voice or fax calls on all ports
Advanced local call switching
The Unified Communications Agent™ (UCA) provides any-to-any multi-path switching (simultaneous SIP H.323 ISDN and POTS calls with routing and conversion between TDM/PSTN and IP/Ethernet networks—plus T.38 and SuperG3 FAX)
Number FXO Ports: 12 2-wire loopstart on 50 or 64 pin Telco connector
Number FXS Ports: 0
Number Ethernet Ports: 1 10/100/1000
Voice Codecs: G.711 a-law/u-law G.723 G.729ab G.726 G.727 T.38 fax G.711
Call switching and services include regular expression-based call routing and number manipulation number blocking short-dialing digit collection distribution and hunt groups and transparent line extension
H.323v4 SIPv2
DTMF in band and out of band
Caller ID detection
Programmable impedance ring detection tone detection disconnect supervision
DHCP Client and server
802.1p ToS DiffServ
802.1Q VLAN tag insertion/deletion (4096 VLAN IDs)
CPU: Motorola MPC875 @ 133MHz
Memory: 32MB SD RAM with 8MB Flash
EMC Compliance: EN 55022 and EN 55024
Safety Compliance: EN 50950
